2013 Schramm T500XD Drill Rig

2013 Schramm T500XD 1500HP Drilling Rig & Package (2) MTU 12V-2000 engines, 760 bhp (567 kw) @ 1,800 rpm with electric start (2) Dual core, side by side cooling pacl‹age, 130”F (54.4“C) ambient rating (2) 220 gallon (930 I) diesel fuel tanks (2) Hydraulic pump systems, with each including (8) piston pumps and (1) gear type pump (1) 1,000 gallon (3,785 I) hydraulic tank with (18) twin element filtersSUB-BASE AND WALKING SYSTEM A dedicated diesel engine, hydraulic pump and 750 gallon (2,839 I) hydraulic tank are included with the systemTELEMAST SYSTEM 0-130,000 lbs. @ 136 fpm (0 - 58,967 kg @ 41m/min) 101,000 — 285,000 lbs. @ 106 fpm (45,813 — 129,274 kg @ 32 in/min) 266,000 — 305,000 lbs. @ 100 fpm (129,727 — 138,346 kg @ 30 in/min) 306,000 — 419,000 lbs. @ 76 fpm (138,799 — 190,055 kg @ 23 in/min) 420,000 — 500,000 lbs. @ 64 fpm (190,509 — 226,796 kg @ 20 in/min) Pulldown Capacity: 80,000 lbs. (36,363 kg) Pulldown Speed: 0-180 fpm (0 — 55 in/min) loaded, 0-200 fpm (0 — 61 in/min) free headTILTING TOP DRIVE Power: 950 bhp (708 kw) Rotation Speed: 0-140 RPM Rotation Torque: Up to 37.5 inch (0.95 in) false table adapter and a 27.5 inch (0.7 in) Master Bushing 22 ft. (6.7 in) floor height 19 ft. (5.79 in) under table clearance HYDRAULIC ROUGHNECK Built-in holding clamps with variable capacity from 4 - 24 inches (10 — 61 cm) allow for make-up or break-out of tool joints from the top drive spindle Capacity: Range III Maximum Lift Capacity: 10,000 lbs. (4,536 kg) Average Water injection system, 35 gpm (132.4 Ipm) @ 1,000 psi (69 bar) DTH lubricator up to 5 gph (19 lph) @ 1,000 psi (69 bar) Air manifold for air drilling operations Air/mud fluid lines, 4 inch (10 cm) stand pipe and traveling hose for 7,500 psi (345bar) operation Explosion proof 240V lighting for nighttime operation (customer supplied generators) BOP handling system, carriage and trolley rated 40,000 lbs. (18,144 kg)Package & Support Equipment: 5" OD (19.5 ppf) Grade S-135 / Range 3 (15,500' ft) NCSO box and pin connections (6 5/8" OD) with hardbandingBOP Equipment: Annular — Cameron type-84 13 5/8 (5,000psi) Ser#112938750-01 Double Ram — Cameron type-U 13 5/8 (10,000psi) Ser#112934297-01 VBR Ram — Cameron type-U 13 5/8 (10,000psi) Ser#112912633-01 Choke Manifold — Cameron 4 1/16 (10,000psi)Trip Tank: Fabricated skid mounted tank with (40 bbl. of capacity) 4 x 3 centrifugal pumpVolume Pit: Fabricated skid mounted tank with roof and 4 Agitators (350 bbl. Capacity) Class 1 Div 1 lightingMud Pumps: (2) 2012 - WHITE STAR QUATRO 1000HP MUD PUMP (can be substituted if preferred, as we do have other options as well)Pump Fully fabricated precision frame with runners on a quadraplex oilfield skid. Precision machined cast alloy steel crossheads Precision crossheads guides with nylatron inserts or bronze Precision pinion and bull gear double helical Forged fully assembled and balanced crankshaft Spherical main and roller conrod bearings Single piece forged 7500psi dual valve fluid modules with liner wear plate Two piece liner system liner with locking nuts and splash guards High Grade polyurethane valves and seats.Power One, Detroit diesel 16V2000P EPA Tier 1, IMO compliant series 2000 16 cylinder, four cycle water cooled, turbo charged, diesel engine rated 1072 continuous BHP @1800 RPM Atex certified with spark arresterL Shape Design External gear reducer clutch engine supports on engine skid 2 brown and sharp #4S lube pump c/w5/3 HP, 50/60HZ, 3 phase 240.480 190/380V Explosion proof electric motor c/w Pre-Filter, pressure gauge and piping (or equivalent) for external lubrication of all quarto bearings, crossheads, guides, etc. Cobra series 118 liner rinse pump c/w 2 HP 50/60 HZ 3-phase 240/480 190/380V marathon explosion proof electric motor with installed circulation system or equal liner rinse pump 2 HP 50/60 HZ 3-phase 240/480190/380V electric motor c/w installed circulation piping system External lubrication system c/w lube pump with electric motor, 1.0hp, 21 60/50hz, 3 phase, 240/480 190/380V or equivalent, strainer, oil-filter, pressure gauge, circulation system. White star standard 2 layers of 2 part epoxy prime and 1 layer of 2 part epoxy top coating
